Product Overview
Product Features
The machine body is wleldd of quality steel sheet and treated by tension elimination, improve stability and reliability of precision of the machine.
In order to guarantee the machine running in stable and smooth, adopts the design of symmetrical two solid boards with balancer.
The precision of mold adjusting up to 0.1mm, safety, reliable and convenient.
Crank, gear, connect bar are oxidized hardening and milled, having super comprehensive mechanical performance and durable function.
Reasonable structural design, is convenient for automatic production and line production.
Used reliable high intensity clutch/brake and twin electroagnetic valve, overloading protector can guarantee sage production all-round.
This machine adopts
Product Advantage
The pneumatic punching press is a versatile and efficient machine used in the brass valve manufacturing process, primarily for precision cutting, forming, and assembling small to medium-sized components. Its reliance on compressed air as a power source makes it suitable for high-speed, clean, and cost-effective production. Below are the key functions of pneumatic punching presses in brass valve production:
Brass valves require numerous small holes, slots, and precise cutouts for fluid control, assembly, and fastening. The pneumatic punching press performs:
Hole Punching: Drilling precise holes for screws, bolts, and valve seat alignment.
Contour Cutting: Trimming excess material from valve bodies, flanges, or connecting ends.
Slot Cutting: Creating grooves for O-rings, seals, or locking mechanisms.
Advantages:
✔ High-speed operation (100–300 strokes/minute) for mass production.
✔ Minimal burr formation due to clean shearing action.
✔ Adjustable stroke and pressure for different brass thicknesses.
Brass valve components often require small bends, flanges, or embossing for functionality. The pneumatic press can:
Flange Forming: Shaping the edges of valve bodies for pipe connections.
Bending Tabs: Creating locking tabs or mounting brackets.
Coining/Embossing: Adding identification marks, logos, or part numbers.
Advantages:
✔ Consistent force application ensures uniform bends.
✔ Quick die changes for multi-stage forming processes.
Many brass valves use press-fit components (e.g., stems, seals, bushings). The pneumatic press assists in:
Bearing & Bushing Insertion: Pressing brass or composite bushings into valve bodies.
Staking/Riveting: Securing moving parts like valve stems or levers.
Seat & Seal Installation: Precisely placing elastomer seals or metal seats.
Advantages:
✔ Controlled force prevents brass deformation.
✔ Repeatable accuracy (±0.02mm) ensures leak-proof assemblies.
Modern brass valve factories use automated pneumatic presses with:
Robotic Feeders: Automatically loading brass sheets or pre-cut blanks.
Ejection Systems: Removing finished parts for conveyor-based sorting.
Vision Systems: Inspecting dimensions and defects in real-time.
Advantages:
✔ Reduces labor costs and human error.
✔ Enlights Industry 4.0 compatibility with IoT monitoring.
Product Overview
Product Features
The machine body is wleldd of quality steel sheet and treated by tension elimination, improve stability and reliability of precision of the machine.
In order to guarantee the machine running in stable and smooth, adopts the design of symmetrical two solid boards with balancer.
The precision of mold adjusting up to 0.1mm, safety, reliable and convenient.
Crank, gear, connect bar are oxidized hardening and milled, having super comprehensive mechanical performance and durable function.
Reasonable structural design, is convenient for automatic production and line production.
Used reliable high intensity clutch/brake and twin electroagnetic valve, overloading protector can guarantee sage production all-round.
This machine adopts
Product Advantage
The pneumatic punching press is a versatile and efficient machine used in the brass valve manufacturing process, primarily for precision cutting, forming, and assembling small to medium-sized components. Its reliance on compressed air as a power source makes it suitable for high-speed, clean, and cost-effective production. Below are the key functions of pneumatic punching presses in brass valve production:
Brass valves require numerous small holes, slots, and precise cutouts for fluid control, assembly, and fastening. The pneumatic punching press performs:
Hole Punching: Drilling precise holes for screws, bolts, and valve seat alignment.
Contour Cutting: Trimming excess material from valve bodies, flanges, or connecting ends.
Slot Cutting: Creating grooves for O-rings, seals, or locking mechanisms.
Advantages:
✔ High-speed operation (100–300 strokes/minute) for mass production.
✔ Minimal burr formation due to clean shearing action.
✔ Adjustable stroke and pressure for different brass thicknesses.
Brass valve components often require small bends, flanges, or embossing for functionality. The pneumatic press can:
Flange Forming: Shaping the edges of valve bodies for pipe connections.
Bending Tabs: Creating locking tabs or mounting brackets.
Coining/Embossing: Adding identification marks, logos, or part numbers.
Advantages:
✔ Consistent force application ensures uniform bends.
✔ Quick die changes for multi-stage forming processes.
Many brass valves use press-fit components (e.g., stems, seals, bushings). The pneumatic press assists in:
Bearing & Bushing Insertion: Pressing brass or composite bushings into valve bodies.
Staking/Riveting: Securing moving parts like valve stems or levers.
Seat & Seal Installation: Precisely placing elastomer seals or metal seats.
Advantages:
✔ Controlled force prevents brass deformation.
✔ Repeatable accuracy (±0.02mm) ensures leak-proof assemblies.
Modern brass valve factories use automated pneumatic presses with:
Robotic Feeders: Automatically loading brass sheets or pre-cut blanks.
Ejection Systems: Removing finished parts for conveyor-based sorting.
Vision Systems: Inspecting dimensions and defects in real-time.
Advantages:
✔ Reduces labor costs and human error.
✔ Enlights Industry 4.0 compatibility with IoT monitoring.
unit | BLC-110 | BLC-160 | BLC-200 | BLC-250 | BLC-315 | |
capacity | ton | 110 | 160 | 200 | 250 | 315 |
rate tonnage point | mm | 5 | 6 | 6 | 7 | 7 |
stroke | mm | 180 | 200 | 250 | 280 | 300 |
stroke per minute | s.p.m | 35-65 | 30-55 | 25-45 | 20-35 | 20-35 |
die height | mm | 400 | 450 | 500 | 550 | 550 |
slide adjustment | mm | 100 | 100 | 120 | 120 | 120 |
slide area | mm | 1400*500*700 | 1600*550*70 | 1850*650*95 | 2100*700*95 | 2100*700*95 |
bolster area | mm | 1800*650*130 | 2000*260*150 | 2400*840*170 | 2700*900*170 | 2750*900*190 |
main motor | kw·p | 11*4 | 15*4 | 18.5*4 | 22*4 | 30*4 |
air pressure | kg/cm² | 6 | ||||
presses precision | GB/JIS 1class | |||||
presses dimension | mm | 1745*2000*3059 | 1940*2200*3709 | 2235*2620*3849 | 2545*3000*4304 | 2545*3010*4689 |
presses weight | ton | 14.2 | 20 | 27.5 | 45.5 | 48 |
unit | BLC-110 | BLC-160 | BLC-200 | BLC-250 | BLC-315 | |
capacity | ton | 110 | 160 | 200 | 250 | 315 |
rate tonnage point | mm | 5 | 6 | 6 | 7 | 7 |
stroke | mm | 180 | 200 | 250 | 280 | 300 |
stroke per minute | s.p.m | 35-65 | 30-55 | 25-45 | 20-35 | 20-35 |
die height | mm | 400 | 450 | 500 | 550 | 550 |
slide adjustment | mm | 100 | 100 | 120 | 120 | 120 |
slide area | mm | 1400*500*700 | 1600*550*70 | 1850*650*95 | 2100*700*95 | 2100*700*95 |
bolster area | mm | 1800*650*130 | 2000*260*150 | 2400*840*170 | 2700*900*170 | 2750*900*190 |
main motor | kw·p | 11*4 | 15*4 | 18.5*4 | 22*4 | 30*4 |
air pressure | kg/cm² | 6 | ||||
presses precision | GB/JIS 1class | |||||
presses dimension | mm | 1745*2000*3059 | 1940*2200*3709 | 2235*2620*3849 | 2545*3000*4304 | 2545*3010*4689 |
presses weight | ton | 14.2 | 20 | 27.5 | 45.5 | 48 |
unit | BLA-25 | BLA-35 | BLA-45 | BLA-60 | BLA-80 | BLA-110 | |
capacity | ton | 25 | 35 | 45 | 60 | 80 | 110 |
rate tonnage point | mm | 3.2 | 3.2 | 3.2 | 4 | 4 | 6 |
speed chaging | s.p.m | 60-140 | 40-120 | 40-100 | 35-90 | 35-80 | 30-60 |
stable speed | s.p.m | 110 | 85 | 75 | 60 | 60 | 50 |
stroke | mm | 70 | 70 | 80 | 120 | 150 | 180 |
die height | mm | 195 | 220 | 250 | 310 | 340 | 360 |
slide adjustment | mm | 50 | 55 | 60 | 70 | 80 | 80 |
slide area | mm | 470*230*50 | 520*285*50 | 560*340*60 | 700*410*70 | 770*420*70 | 910*470*80 |
bloster area | mm | 680*300*70 | 800*400*70 | 850*440*80 | 900*500*80 | 1000*550*90 | 1150*600*110 |
main motor | kw·p | 3.7*4 | 3.7*4 | 5.5*4 | 5.5*4 | 7.5*4 | 11*4 |
slide adjust device | HP | manual operation | electrical operation | ||||
air pressure | kg/cm² | 6 | |||||
presses precision | GB/JIS 1class | ||||||
presses dimension | mm | 1280*850*2200 | 1380*900*2400 | 1600*950*2500 | 1600*1000*2800 | 1800*1180*2800 | 1900*1300*3200 |
presses weight | ton | 2.1 | 3 | 3.8 | 5.6 | 6.5 | 9.6 |
unit | BLA-160 | BLA-200 | BLA-260 | BLA-315 | BLA-400 | |
capacity | ton | 160 | 200 | 260 | 315 | 400 |
rate tonnage point | mm | 6 | 6 | 7 | 8 | 8 |
speed chaging | s.p.m | 20-50 | 20-50 | 20-40 | 20-40 | 20-40 |
stable speed | s.p.m | 35 | 35 | 30 | 30 | 30 |
stroke | mm | 200 | 200 | 250 | 250 | 250 |
die height | mm | 460 | 460 | 500 | 500 | 550 |
slide adjustment | mm | 100 | 110 | 120 | 120 | 120 |
slide area | mm | 990*550*90 | 1130*630*90 | 1250*700*100 | 1250*750*100 | 1350*800*100 |
bloster area | mm | 1250*800*140 | 1400*820*160 | 1500*840*180 | 1600*860*190 | 1650*900*200 |
main motor | kw·p | 15*4 | 18.5*4 | 22*4 | 30*4 | 37*4 |
slide adjust device | HP | electrical operation | ||||
air pressure | kg/cm² | 6 | ||||
presses precision | GB/JIS 1class | |||||
presses dimension | mm | 2300*1400*3800 | 2615*1690*4075 | 2780*1850*4470 | 2910*1950*4500 | 3180*2150*5025 |
presses weight | ton | 16 | 23 | 32 | 35 | 40 |
unit | BLA-25 | BLA-35 | BLA-45 | BLA-60 | BLA-80 | BLA-110 | |
capacity | ton | 25 | 35 | 45 | 60 | 80 | 110 |
rate tonnage point | mm | 3.2 | 3.2 | 3.2 | 4 | 4 | 6 |
speed chaging | s.p.m | 60-140 | 40-120 | 40-100 | 35-90 | 35-80 | 30-60 |
stable speed | s.p.m | 110 | 85 | 75 | 60 | 60 | 50 |
stroke | mm | 70 | 70 | 80 | 120 | 150 | 180 |
die height | mm | 195 | 220 | 250 | 310 | 340 | 360 |
slide adjustment | mm | 50 | 55 | 60 | 70 | 80 | 80 |
slide area | mm | 470*230*50 | 520*285*50 | 560*340*60 | 700*410*70 | 770*420*70 | 910*470*80 |
bloster area | mm | 680*300*70 | 800*400*70 | 850*440*80 | 900*500*80 | 1000*550*90 | 1150*600*110 |
main motor | kw·p | 3.7*4 | 3.7*4 | 5.5*4 | 5.5*4 | 7.5*4 | 11*4 |
slide adjust device | HP | manual operation | electrical operation | ||||
air pressure | kg/cm² | 6 | |||||
presses precision | GB/JIS 1class | ||||||
presses dimension | mm | 1280*850*2200 | 1380*900*2400 | 1600*950*2500 | 1600*1000*2800 | 1800*1180*2800 | 1900*1300*3200 |
presses weight | ton | 2.1 | 3 | 3.8 | 5.6 | 6.5 | 9.6 |
unit | BLA-160 | BLA-200 | BLA-260 | BLA-315 | BLA-400 | |
capacity | ton | 160 | 200 | 260 | 315 | 400 |
rate tonnage point | mm | 6 | 6 | 7 | 8 | 8 |
speed chaging | s.p.m | 20-50 | 20-50 | 20-40 | 20-40 | 20-40 |
stable speed | s.p.m | 35 | 35 | 30 | 30 | 30 |
stroke | mm | 200 | 200 | 250 | 250 | 250 |
die height | mm | 460 | 460 | 500 | 500 | 550 |
slide adjustment | mm | 100 | 110 | 120 | 120 | 120 |
slide area | mm | 990*550*90 | 1130*630*90 | 1250*700*100 | 1250*750*100 | 1350*800*100 |
bloster area | mm | 1250*800*140 | 1400*820*160 | 1500*840*180 | 1600*860*190 | 1650*900*200 |
main motor | kw·p | 15*4 | 18.5*4 | 22*4 | 30*4 | 37*4 |
slide adjust device | HP | electrical operation | ||||
air pressure | kg/cm² | 6 | ||||
presses precision | GB/JIS 1class | |||||
presses dimension | mm | 2300*1400*3800 | 2615*1690*4075 | 2780*1850*4470 | 2910*1950*4500 | 3180*2150*5025 |
presses weight | ton | 16 | 23 | 32 | 35 | 40 |
unit | BLM-110 | BLM-160 | BLM-200 | BLM-250 | BLM-300 | BLM-400 | BLM-500 | BLM-630 | |
capacity | ton | 110 | 160 | 200 | 250 | 300 | 400 | 500 | 630 |
rate tonnage point | mm | 5 | 6 | 6 | 7 | 7 | 7 | 7 | 7 |
stroke | mm | 180 | 180 | 250 | 280 | 300 | 300 | 300 | 300 |
stroke per minute | s.p.m | 35-65 | 30-55 | 20-50 | 20-40 | 20-35 | 20-40 | 15-25 | 15-25 |
die height | mm | 400 | 450 | 500 | 550 | 550 | 550 | 600 | 600 |
slide adjustment | mm | 100 | 100 | 120 | 120 | 120 | 120 | 150 | 200 |
slide area | mm | 1400*550 | 1600*650 | 1850*750 | 2400*900 | 2400*900 | 2620*1000 | 3200*1200 | 3740*1300 |
bolster area | mm | 1550*750 | 1800*760 | 2200*940 | 2500*600 | 2500*1000 | 2700*1100 | 3400*1200 | 4000*1400 |
slide oppening | mm | 600*350 | 700*450 | 900*600 | 900*600 | 900*600 | 900*600 | 1000*700 | 1000*700 |
main motor | kw·p | 11*4 | 15*4 | 18.5*4 | 30*4 | 30*4 | 37*4 | 55*4 | 75*4 |
air pressure | 6 | ||||||||
presses precision | GB/JIS 1class | ||||||||
presses dimension | mm | 2155*2280*3180 | 2309*2590*3682 | 2523*3000*3915 | 2799*3600*4593 | 2899*3600*4729 | 3225*3800*5150 | 3655*4500*5150 | 3955*5100*5971 |
unit | BLM-110 | BLM-160 | BLM-200 | BLM-250 | BLM-300 | BLM-400 | BLM-500 | BLM-630 | |
capacity | ton | 110 | 160 | 200 | 250 | 300 | 400 | 500 | 630 |
rate tonnage point | mm | 5 | 6 | 6 | 7 | 7 | 7 | 7 | 7 |
stroke | mm | 180 | 180 | 250 | 280 | 300 | 300 | 300 | 300 |
stroke per minute | s.p.m | 35-65 | 30-55 | 20-50 | 20-40 | 20-35 | 20-40 | 15-25 | 15-25 |
die height | mm | 400 | 450 | 500 | 550 | 550 | 550 | 600 | 600 |
slide adjustment | mm | 100 | 100 | 120 | 120 | 120 | 120 | 150 | 200 |
slide area | mm | 1400*550 | 1600*650 | 1850*750 | 2400*900 | 2400*900 | 2620*1000 | 3200*1200 | 3740*1300 |
bolster area | mm | 1550*750 | 1800*760 | 2200*940 | 2500*600 | 2500*1000 | 2700*1100 | 3400*1200 | 4000*1400 |
slide oppening | mm | 600*350 | 700*450 | 900*600 | 900*600 | 900*600 | 900*600 | 1000*700 | 1000*700 |
main motor | kw·p | 11*4 | 15*4 | 18.5*4 | 30*4 | 30*4 | 37*4 | 55*4 | 75*4 |
air pressure | 6 | ||||||||
presses precision | GB/JIS 1class | ||||||||
presses dimension | mm | 2155*2280*3180 | 2309*2590*3682 | 2523*3000*3915 | 2799*3600*4593 | 2899*3600*4729 | 3225*3800*5150 | 3655*4500*5150 | 3955*5100*5971 |
